MC68HC11 Single Board Computer
I designed this card to be used in a PCB-drilling system.
Currently I am using it to test and prototype different
68HC11 based projects.
Configuration
Motorola MC68HC11A1 microcontroller
1 socket for EPROM (2716-27256)
Modified EURO-6 bus
RS-232C asynchronous serial port
